CellPower CPC135-12 accu Replaced by CPXC135-12HE

Nominal voltage 12 V DC

Nominal Capacity (5HR,20grC): 118 Ah
Nominal Capacity (10HR,20grC): 135 Ah
Nominal Capacity (20HR,20grC): 144 Ah

Internal resistance Approx. 3.8 m Ω
Maximum charging current 40.2 A
Maximum discharge current 950 A (5 sec.)
Number of cycles 600 (50% D.O.D.)
Operating temperature range -20grC  50grC
Float use/ cycle use 13.6 – 13.8V/ 14.5 – 14,9V
Standard terminal Threaded Insert 8mm
Housing material ABS (UL94-HB)

Dimensions length 341 mm width 173 mm height 287 mm (1 mm)
Approx. Weight 40 kg
Packing 1 pcs/box
