Planet ICS-100

Access Control System – Traditional Installation
Most of the enterprises and governments use access control plate and Mifare or RFID to authorize entrance identity. With the traditional deployment, access control machine uses RS-232 or RS-485 serial interface and cables connecting to login server. With connection to ICS-10x serial over Fast Ethernet Converter, the access control machine is able to extend over longer distances via Ethernet. Or the ICS-10x can be linked to an XDSL router to get the internet access capability; the access control can be set and monitored over the Internet.

Process Control
To monitor, configure and manage the Robot conveyer including other manufacturing machines, PLC (Programmable Logical Control) is required. The PLC is used to drive the above the manufacturing process. The ICS-10x can be set to TCP server mode and connect the PLC. The administrator can configure and set command settings through Fast Ethernet intranet to control the PLC, the administrator and workstation. There is no need for the adminstrators to be always by the side of the I/O machine.

RTU Data Collect – UDP Mode
Connect with RTU (Remote Terminal Unit) to collect and monitor the data of waves, signal and power utilization. The ICS-10x can be used to set up UDP mode and send data over Fast Ethernet to Local server or over Internet to remote server automatically.

Surveillance Motion Control – Pair Connection Mode
Using pair connection along with fiber optic patch cord, the ICS-10x extends RS-232 / RS-422 / RS-485 interface distance from surveillance and scanner to the control keyboard/joystick which is installed in the remote monitoring center.
